gate valve, is a valve that opens by lifting a round or rectangular gate/wedge out of the path of the fluid. the distinct feature of a gate valve is the sealing surfaces between the gate and seats are planar, so gate valves are often used when a straight-line flow of fluid and minimum restriction is asked. gate valves are characterized as having either a rising or a non-rising stem. rising stems provide a visual indication of valve position because the stem is attached to the gate such that the gate and stem rise and lower together as the valve is operated. non-rising stem valves may have a pointer threaded onto the upper end of the stem to indicate valve position. non-rising stems are used underground or where vertical space is limited.

1)design rating:api600
2)face to face:amse b16.10
3)flanged ends:asme b16.5
4)inspection&testing:api 598
5)size:1/2" - 40"
6)material: cf8/cf8m/cf3/cf3m/lcb/wcb, lcb, wc6, wc9, c12, c5

7)operated by: handwheel, gear, pneumatic, hydraulic and electric actuator.

• origin: wenzhou
• packing: plywood case
• brand name: apirt
• delivery time: 30 days
• minimum order: 1pcs
• supply ability: 1000pcs/month
• quality system certification: ce, iso9001, api 6d
