bevel gear stop valve

the release date：[2017-08-07] hits

bevel gear globe valve

stainless steel bevel gear globe valve overview:

the opening and closing of the stainless steel bevel gear valve is a plug-shaped disc with a flat or conical surface, and the flap moves linearly along the centerline of the fluid. the movement of the stem, there are lift rod (stem lift, hand wheel does not lift), there are lifting rod (hand wheel and stem together with the lift, the nut is located on the valve body). the globe valve is only suitable for full and full clearance, and is not allowed for adjustment and throttling.

standard specification for performance of stainless steel bevel gears

body material		nominal pressure (mpa)	working temperature (℃)	applicable media
carbon steel		10.0	≤425	water, oil, steam
stainless steel	p	10.0	≤ 200	nitric acid
	r			acetic acid
chrome-molybdenum steel		10.0	≤550	oil, steam
