the two piece female thread connecting ball valve of ruitong has the valve body cast using advanced process introduced from taiwan, reasonable in structure and elegant in appearance; the valve seat is of elastic seal structure, reliably sealed and easily opened and closed; the valve rod is of bottom mounting structure with back seal, and will not fly out in case of abnormal pressure rise inside the valve cavity. the valve can be equipped with iso standard support platform, locking device, and 90° switch locating mechanism. the valve can thus be locked as required to prevent accidental operations. there are three drive modes, manual, electric and pneumatic modes.

2pc threaded ball valve
design rating:api608
face to face: amse b16.10
flanged ends: asme b16.5
inspection& testing:api 598
size:1/2" - 24"
material: cf8/cf8m/cf3/cf3m/lcb/wcb, lcb, wc6, wc9, c12, c5
operated by: hand wheel, gear, pneumatic, hydraulic and electric actuator.

1) structure: 2pc body
2) size: 1/2"-4"
3) rating: 1000psi~3000psi
4) material: cf8, cf8m, cf3, cf3m, a216, a105
5) end connection: npt
6) operation: handle lever(optional locked device)
7) application: industrial usage

•product name: 2pc threaded ball valve
•origin: wenzhou
•packing: plywood case
•brand name: apirt
•delivery time: 30 days
•minimum order: 1pcs
•supply ability: 1000pcs/month
•quality system certification: ce, iso9001, api 6d
