ansi flanged ball valve
the release date：[2017-08-07] hits
 |
 |
 |
ball valves, carbon steel ball valve, us ball valve, wcb ball valve, cast steel ball valve
applicable medium: water, gas, oil, and corrosive medium such as acids, alkalis etc.
applicable temperature:-29~150°c
driving methods: manual, pneumatic, electric and hydraulic
size: 1/2"~ 48" , dn 15-1200mm
pressure : ansi class 150 - class 2500lb
material :cs,ss,alloy
1. side entry design
2. bolted body
3. full bore or reduced bore
4. flanged end
5. double block and bleed
6. locking device.
7. single piston effect , double piston effect
8. automatic internal relief of body pressure
9. emergency sealant injection system
10. anti-blowout stem design
11. body vent device
12. stem extension for underground service
