stainless steel ball valve

the release date：[2017-08-07] hits

product information - api american standard ball valve

flying ball valve features: feature: 1, full diameter, floating / fixed ball 1, full port, floating or trunnion mounte type
2, the middle flange bolts 2, bolted bonnet
3, out of the stem 3, blow outbreak stem
4, fire and anti-static safety
5, american standard structure improved 5, structure improve on api
6, opening and closing positioning mechanism 6, opening and closing position
7, worm gear operation optional 7, available with wormgear operator
8, standard flange connection 8, fanged ends

american standard flange ball valve product specification

product specification

product

specification

design specification

design spec

structure length

face to face

connecting flange

flange end

test and test

test & check

product identification

marking

supply specification

supply

api608

asme b16.10

ansi b16.5

api598

mss sp-25

api608

api6d

american standard flange ball valve technical specifications

design basis	standard series	american standard series
design standards	bs5351	ap16d	ansi b16.34
flange connection structure length	jis b2002	ap16d	ansi b16.10
structure length (welding)	-	ap16d	ansi b16.10
connecting flange	jis b2212 b2214	ansi b16.5, b16.47
butt end	-	ansi b16.25
test and test	jis b2003	ap16d	ap1598

american standard flange ball valve main parts material main part material

part name	零部件材料 part material										part name
阀体/阀盖	a216-wcb	a105		a352-lc8	a351-cf8		a351-cf8m	a351-cf3		a351-cf3m	body/bonnet
球体	a182-f304	a182-f304		a182-f304	a182-f304		a182-f316	a182-f304l		a182-f316l	ball
阀杆	a182-f6a	a182-f6a		a182-f6a	a182-f304		a182-f316	a182-f304l		a182-f316l	stem
阀座	a105				a182-f304		a182-f316	a182-f304l		a182-f316l	seat ring
密封圈	ptfe				r.ptfe						seat
填料	聚四氟乙烯/ptfe fpm				聚四氟乙烯/ptfe fpm						packing
垫片	18-8柔性石墨/18-8/flexible graphite 聚四氟乙烯/ptfe fpm										gasket
螺栓	a193-b8					a193-b8m					bolt
适用温度	-29~121℃		-40~121℃			-40~121℃			-40~121℃		suitable temp
适用介质	水、油品、蒸汽 water、oil、steam					硝酸类 nitric acid			醋酸类 acetic acid		suitable medium

美标法兰球阀主要外形和连接尺寸main external and connection

美标法兰球阀主要外形和连接尺寸 main external and connection dimension 单位 unit: mm

产品型号	nps	dn	class 150lb								wt
type	in	mm	l	d	d1	d2	b	z-фd	h	w	(kg)
q41f-150lb	1/2"	15	108	89	60.5	35	11.2	4-ф15.8	55	125	2.3
q41f-150lbp	3/4"	20	117	98	70	43	12.7	4-ф15.8	55	125	3
	1"	25	127	108	79.5	51	14.3	4-ф15.8	70	160	4.5
q341f-150lb	1¼"	32	140	117	89	64	15.7	4-ф15.8	75	160	5.5
q341f-150lbp	1½"	40	165	127	98.5	73	17.5	4-ф15.8	90	190	7
	2"	50	178	152	120.5	92	19.1	4-ф19	104	350	9.5
q641f-150lb	2½"	65	190	178	139.5	105	22.3	4-ф19	153	400	15
q641f-150lbp	3"	80	203	190	152.5	127	23.9	4-ф19	187	489	19
	4"	100	229	229	190.5	157	23.9	8-ф19	206	500	33
q9b41f-150lb	5"	125	356	254	216	186	23.9	8-ф22.2	244	600	58
q9b41f-150lbp	6"	150	394	279	241.5	216	25.4	8-ф22.2	252	600	93
	8"	200	457	343	298.5	270	28.5	8-ф22.2	283	735	160
	10"	250	533	406	362	324	30.2	12-ф25.4	345	800	200
