2pc flanged ball valve with high mounting pad a ball valve is a form of quarter-turn valve which uses a hollow, perforated and floating ball to control flow through it. it is open when the ball's hole is in line with the flow and closed when it is pivoted 90-degrees by the valve handle. the handle lies flat in alignment with the flow when open, and is perpendicular to it when closed, making for easy visual confirmation of the valve's status. ball valves are durable, performing well after many cycles, and reliable, closing securely even after long periods of disuse. these qualities make them an excellent choice for shutoff applications, where they are often preferred to gates and globe valves the ball valve's ease of operation, repair, and versatility lend it to extensive industrial use, supporting pressures up to 1000 bar and temperatures up to 752°f (500°c), depending on design and materials used. sizes typically range from 0.2 to 48 inches (0.5 cm to 121 cm). it is open when the ball's hole is in line with the flow and closed when it is pivoted 90-degrees by the valve handle.

low platfor stainles steel ball valve

key words: stainless steel ball valve, low platform ball valve

2. pressure: 150lb, 300lb, 600lb

3. material: stainless steel, 304, 316,316l, cf8, cf8m

4. size: 1/2"-12"

5. connection: flange

6. design standard: api608, api6d, gb/t12237

7. face to face:ansi b16.1, api 6d

8. flange end: ansi b16.5

9. inspection: api 598
