api cast steel gate valve

the release date：[2017-08-07] hits

american standard cut valve features: feature
1. streamlined, with rod with bracket 1.streamline outside screw and yoke
2. middle flange bolted 2.bolted bonnet
3. sleeve connection valve 3.loose disc
4. lifting valve stem handwheel 4.rising stem and hand wheel
american standard valve product specification product specification

product specification

product

specification

design specification

design spec

structure length

face to face

connecting flange

flanged end

test and test

test & check

pressure - temperature

pressure-temp

product identification

marking

supply specification

supply

api600

ansi b16.10

ansi b16.5

api598

asme b16.34

api6d

api600

api6d

mss sp-25

api standard valve list material list

part name	part material					part name
body / bonnet	a216-wcb	a217-wc6		a352-lcb	a351-cf8m	body / bonnet
gate	a216-wcb	a217-wc6		a352-lcb	a351-cf8m	wedge
stem	a182-f6a	a182-f11		a182-f6a	a182-f316	stem
filler	flexible graphite				polytetrafluoroethylene / ptfe	packing
gasket	18-8 flex graphite / 18-8flexible graphite					gasket
bolt	a193-b7		a193-b7	a193-b7m	a193-b8	bolt
proper temperature	-29 to 425 ° c		-29 ~ 550 ℃	-46 to 350 ° c	-40 ~ 200 ℃	suitable for temp
applicable media	water, oil, steam water, oil, steam		steam, oil steam, oil	propane, ethylene propane, ethane	nitric acid nitric acid	suitable medium

api美标法兰闸阀主要外形和连接尺寸main external and connection

美标闸阀尺寸列表dimension 单位 unit:mm

api美标法兰闸阀尺寸列表dimension 单位 unit:mm
产品型号	nps	dn	class 150lb								wt（kg）
type	in	mm	l	d	d1	d2	b	z-φd	h	d0	wt（kg）
z40h-150lb	2"	50	178	152	120.5	92	16	4-φ19	323	200	18
(body:wcb)	21/2"	65	190	178	139.5	105	18	4-φ19	347	250	28
z40w-150lbp	3"	80	203	190	152.5	127	19	4-φ19	383	250	30
(body:cf8)	4"	100	229	229	190.5	157	24	8-φ19	457	300	50
z40y-150lbp	5"	125	254	254	216	186	24	8-φ22	632	300	63
(body:cf8)	6"	150	267	279	241.5	216	26	8-φ22	635	350	85
z40y-150lbr	8"	200	292	343	298.5	270	29	8-φ22	762	350	128
(body:cf8m)	10"	250	330	406	362	324	31	12-φ25	895	400	220
z40y-150lbpl	12"	300	356	483	432	381	32	12-φ25	1080	500	310
(body:cf3)	14"	350	381	533	476	413	35	12-φ29	1295	600	450
z40y-150lbrl	16"	400	406	597	540	470	37	16-φ29	1435	600	550
(body:cf3m)	18"	450	432	635	578	533	40	16φ32	1626	650	700
	20"	500	457	699	635	584	43	20φ32	1829	650	910
	24"	600	508	813	749.5	692	48	20φ35	2175	700	1130
api美标法兰闸阀尺寸列表dimension 单位 unit:mm
产品型号	nps	dn	class 300lb								wt（kg）
type	in	mm	l	d	d1	d2	b	z-φd	h	d0	wt（kg）
z40h-300lb	2"	50	216	165	127	92	22	8-φ19	330	250	30
(body:wcb)	2"	50	216	165	127	92	22	8-φ19	330	250	30
z40w-300lbp	21/2"	65	241	190	149	105	25	8-φ22	368	250	36
(body:cf8)	3"	80	283	210	168.5	127	29	8-φ22	394	300	61
z40y-300lbp	4"	100	305	254	200	157	32	8-φ22	473	300	77
(body:cf8)	5"	125	381	279	235	186	35	8-φ22	660	350	106
z40y-300lbr	6"	150	403	318	270	216	37	12-φ22	711	350	153
(body:cf8m)	8"	200	419	381	330	270	41	12-φ25	813	400	286
z40y-300lbpl	10"	250	457	444	387.5	324	48	16-φ29	1003	500	412
(body:cf3)	12"	300	502	521	451	381	51	16φ32	1137	600	576
z40y-300lbrl	14"	350	762	584	514.5	413	54	20φ32	1489	600	886
(body:cf3m)	16"	400	838	648	571.5	470	57	20φ35	1581	650	1175
api美标法兰闸阀尺寸列表dimension 单位 unit:mm
产品型号	nps	dn	class 600lb								wt（kg）
type	in	mm	l	d	d1	d2	b	z-φd	h	d0	wt（kg）
	2"	50	292	165	127	92	26	8-φ19	510	254	44
z40h-600lb	21/2"	65	330	190	149	105	29	8-φ22	554	254	60
(body:wcb)	3"	80	356	210	168.5	127	32	8-φ22	595	305	80
z40w-600lbp	4"	100	432	273	216	157	38	8-φ25	712	356	145
(body:cf8)	5"	125	508	330	266.5	186	45	8-φ29	826	406	236
z40y-600lbp	6"	150	559	356	292	216	48	12-φ29	995	508	309
(body:cf8)	8"	200	660	419	349	270	56	12-φ32	1157	610	522
z40y-600lbr	10"	250	787	508	432	324	64	16-φ35	1373	686	779
(body:cf8m)	12"	300	838	559	489	381	67	20-φ35	1603	686	1108
z40y-600lbpl	14"	350	889	603	527	413	70	20-φ38	1930	762	1503
(body:cf3)	16"	400	991	686	603	470	77	20-φ41	2032	889	1939
z40y-600lbrl	18"	450	1092	743	654	533	90	20-φ44	2286	889	2733
(body:cf3m)	20"	500	1194	813	724	584	96	24-φ44	2591	1118	3214
	24"	600	1397	940	838	692	109	24-φ52	3124	1118	4177

5.支架与阀盖一体式 5.yoke integral with bonnet
6.伞齿轮操作选配 6.avail able with gear operator
7.标准法兰连接 7.flanged ends
美标法兰截止阀产品规范product specification

不锈钢美标截止阀产品规范 product specification

产品规范

product

specification

设计规范design spec

结构长度face to face

连接法兰flanged end

试验与检验test &check

压力-温度pressure-temp

产品标识marking

供货规范

supply

asme b16.34

ansib 16.10

ansib 16.5

api598

asme b 16.34

mss sp-25

asme b16.34

bs 5160

美标法兰截止阀主要零部件材料 main part material

零件名称	零部件材料 part material				part name
阀体/阀盖	a216-wcb	a217-wc6	a352-lcb	a351-cf8m	body/bonnet
闸瓣	a105	a182-f11	a182-f304	a182-f316	disk
阀杆	a182-f6a	a182-f11	a182-f6a	a182-f316	stem
填料	柔性石墨/ flexible graphite			聚四氟乙烯/ptfe	packing
垫片	18-8柔性石墨/18-8flexible graphite				gasket
螺栓	a193-b7	a193-b7	a193-b7m	a193-b8	bolt
适用温度	-29~425℃	-29~550℃	-46~350℃	-40~200℃	suitable temp
适用介质	水，油品，蒸汽 water，oil，steam	蒸汽，油品 steam，oil	丙烷，乙烯 propane，ethane	硝酸类 nitric acid	suitable medium

美标法兰截止阀主要外形和连接尺寸main external and connectio

美标法兰截止阀尺寸列表dimension list

产品型号 type	nps	dn	class 150lb								wt（kg）
产品型号 type	in	mm	l	d	d1	d2	b	z-φd	h	d0	wt（kg）
j41h-150lb j41w-150lbp j41y-150lbp j41y-150lbr j41y-150lbpl j41y-150lbrl	1/2"	15	108	89	60.5	35	10	4-φ15	169	125	5.0
	3/4"	20	117	98	70	43	11	4-φ15	180	125	7.0
	1"	25	127	108	79.5	51	12	4-φ15	190	125	9.0
	11/4"	32	140	117	89	63	13	4-φ15		160
	11/2"	40	165	127	98.5	73	14.3	4-φ16	347	180	15.0
	2"	50	203	152	120.5	92	15.9	4-φ19	356	180	18
	21/2"	65	216	178	139.5	105	17.5	4-φ19	381	240	30
	3"	80	241	190	152.5	127	19.1	4-φ19	411	280	41
	4"	100	292	229	190.5	157	24	8-φ19	454	280	64
	5"	125	356	254	216	186	24	8-φ22	541	320	86
	6"	150	406	279	241.5	216	25.4	8-φ22	656	360	113
	8"	200	495	343	298.5	270	29	8-φ22	800	450	115
	10"	250	622	406	362	324	31	12-φ25	1231	500	295
	12"	300	698	483	432	381	32	12-φ25	1450	600	450

美标法兰截止阀尺寸列表dimension list

产品型号type	nps	dn	class 300lb								wt（kg）
产品型号type	in	mm	l	d	d1	d2	b	z-φd	h	d0	wt（kg）
j41h-300lb j41w-300lbp j41y-300lbp j41y-300lbr j41y-300lbpl j41y-300lbrl	1/2"	15	152	95	66.5	35	15	4-φ15	241	125	5.2
	3/4"	20	178	117	82.5	43	16	4-φ19	241	125	7.3
	1"	25	203	124	89	51	18	4-φ19	283	160	9.5
	11/4"	32	216	133	98.5	63	19	4-φ19	320	200
	11/2"	40	229	156	114.3	73	21	4-φ22	322	200	17.6
	2"	50	267	165	127	92	23	8-φ19	399	200	25
	21/2"	65	292	190	149	105	26	8-φ22	438	250	30
	3"	80	318	210	168.5	127	29	8-φ22	464	280	35
	4"	100	356	254	200	157	32	8-φ22	565	355	56
	5"	125	400	279	235	186	35	8-φ22	614	400	96
	6"	150	444	318	270	216	37	12-φ22	717	450	120
	8"	200	559	381	330	270	42	12-φ25	930	500	212
	10"	250	622	444	387.5	324	48	16-φ29	1012	500	460
	12"	300	711	521	451	381	51	16-φ32	1231	600	615
