ruitong valve suppling many kind of ball valves :floating type ball valve,trunnion ball valve api flanged ball valve;api carbon steel ball valve; api stainless steel ball valve,threaded ball valve etc. api ball valve is a valve with its ball floating (not fixed by a trunnion) inside the valve body, it drifts toward to the downstream side and tightly pushes against the seat under the medium pressure to ensure sealing reliability. the floating ball valve has simple structure, good sealing performance but the seat material is required to withstand the workload since the sealing pressure is bared by the seat ring. due to unavailability of high performance seat material, floating ball valve is mainly used in middle or low pressure application.

product description

gas industrial floating motorized control ball valve 3"

product description

1. 300lb carbon steel flanged ball valve features

applicable medium: water, gas, oil, and corrosive medium such as acids, alkalis etc.

applicable temperature:-196~350°c

driving methods: manual, pneumatic, electric and hydraulic

size: 1/2"~ 48" , dn 15-1200mm
pressure : ansi class 150 - class 2500lb
material :cs,ss,alloy

1. side entry design

2. bolted body

3. full bore or reduced bore

4. flanged end

5. double block and bleed

6. locking device.

7. single piston effect , double piston effect

8. automatic internal relief of body pressure

9. emergency sealant injection system

10. fire safe design. antistatic device

11. anti-blowout stem design

12. body vent device

13. stem extension for underground service.

2. api gear operated flanged ball valve major parts and materials
